Installation is carried out in reverse sequence; note the following: |
–
| Apply grease -G 000 450 02- to all bearings and contact surfaces. |
–
| Install clutch pedal -3-, push in pivot pin -1- and lock in direction of -arrow A-. Bottom of retaining tab -2- should engage at pedal bracket. |
–
| Insert locking pin -4-. Shoulder on pin -arrow B- must be introduced into groove on clutch pedal. |
|
|
|
