A6 V6-3.0L (AVK) (2004)
/Page-4777001.png)
Ball Joint: Service and Repair
Bonded Rubber Bushing For Wheel Bearing Housing, Removing and Installing
Bonded rubber bushing for wheel bearing housing, removing and installing
Special tools and equipment
^
VW412 punch
^
VW 519 pipe piece
^
VW401 thrust plate
^
3292/3/4 pressure piece
^
3292 installation tool
^
3349 puller
Bonded rubber bushing in wheel bearing housing consists of two parts. Therefore, removal and installation is performed in two work sequences.
Removing
Pressing out first bonded rubber bushing
^
Slightly flange sheet metal collars of bonded rubber bushing.
