A6 Quattro Sedan V6-3.2L (BKH) (2005)
/Page-2147004.png)
-
Apply a 2-3mm wide Sealant Bead all around the outside of the NEW sealing cap as shown.
-
Install NEW caps flush in each hole within less than 3 minutes after applying the sealant on cap.
Tip:
Use a flat tool, such as a Snap-on(R) CSA8C gasket scraper (see picture), to push the Sealing Caps into bore holes in order not to push them all the way
inside cylinder head.
-
After installation, clean up glue residue from outside of caps.
Tip:
The open side of the cap is pointing inside the cylinder head.
In order NOT to remove the coolant hose located in front of Bank 2, the Sealing Cap C does not need to be replaced.
Only Reseal Sealing Cap C as follows:
