A6 Quattro Sedan V8-4.2L (BVJ) (2007)
Overview.
‹› Tightening specifications, refer to => [ Fastener Tightening Specifications ] See: Fuel Delivery and Air Induction/Specifications/Fuel Supply
System - Fastener Tightening Specifications.
Installation is performed in reverse order of removal, noting the following:
-
Engage the accelerator pedal module - 4 - on the bottom of the pedal bracket - 1 -, insert the centering pin - 2 - and tighten the bolt - 3 -.
-
Install the driver side lower instrument panel cover.
Vehicles with automatic transmission:
-
Perform after the first kick-down adaptation in "Guided Functions ".
