A6 Quattro Sedan V8-4.2L (BVJ) (2007)
Alignment: Procedures
Front Axle Camber, Checking and Evening Out If Necessary
Front axle camber, checking and evening out if necessary
Camber cannot be adjusted.
It is possible to even out camber uniformly within expected tolerance range by shifting carrier.
-
Remove noise insulation.
-
Loosen hex bolts - 1 - to - 12 -.
-
Slide subframe with engine mount and stabilizer bar into respective position using a plastic coated tire iron.
Press at center of subframe between subframe and body long member.
