A6 Quattro Sedan V8-4.2L (BVJ) (2007)
-
Insert wheel hub support (T10149) into engine/transmission jack (V.A.G 1383 A) and press wheel bearing housing far enough upward until
control position, dimension - a -, is obtained.
Control position
‹› Dimension - a - for vehicles with air suspension 386 mm
‹› Dimension - a - for Allroad vehicles with air spring 388 mm
CAUTION!
‹› Do not lift or lower vehicle when the engine/transmission jack stands below the vehicle.
‹› Do not leave engine/transmission jack below vehicle any longer than necessary.
Working after adjusting control position
-
Tighten respective bolts/nuts.
-
Lower wheel bearing housing.
-
Remove engine/transmission jack under vehicle.
-
Remove wheel hub support (T10149).
-
Connect connecting piece - 1 - at residual pressure valve - 2 - => [ (Item 8) Connector piece ] See: Suspension/Suspension Control ( Automatic -
Electronic )/Air Spring/Service and Repair/Removal and Replacement/Front Suspension/Air Suspension Strut, Mounting Bracket and Upper
Control Arm Assembly Overview.
