A6 Quattro Sedan V8-4.2L (BVJ) (2007)

Page 1
background image

Wiper Motor: Service and Repair
Rear Window Wiper Motor Assembly Overview

Rear Window Wiper Motor Assembly Overview

1

Nut - 8 Nm

2

Rear Window Wiper Motor (V12)

‹› Removing and installing, refer to => [ Rear Window Wiper Motor ] See: Rear Window Wiper Motor

3

Seal

4

Washer fluid hose
