A8L V8-4.2L (BFM) (2004)
Relay Box: Application and ID
Fuse and Relay Arrangement on Relay Panels
Relay and Fuse Panel behind Instrument Panel, left
Relay And Fuse Panel Behind Instrument Panel, Left
Relay Location
1
-
Relay for Compressor Level Control System, J403
2
-
Horn Relay, J4
3
-
Voltage Supply Terminal 15 (B+) Relay, J329
4
-
Windshield Washer Fluid Heating Relay, J711
6
-
Power Supply Relay 1 (terminal 75), J680
Fuse Location
A -
Fuse 1 for Control Module - ABS, S123
B -
Self-Levelling System Fuse, S110
C -
Power Window Circuit Breaker, S43
D -
Power Seat Circuit Breaker 1, S44
E
-
Power Seat Circuit Breaker 2, S45
Relay Panel In Front Footwell, Right
Relay Panel In Front Footwell, Right
Relay Location
2
-
Starter Relay, J53
3
-
Starter Relay 2, J695
