Allroad Quattro V8-4.2L (BAS) (2004)
Steering Angle Sensor: Service and Repair
Steering angle sensor -G85-, removing and installing
Removing
WARNING:
^
Before removing steering wheel, wheels must be positioned in the straight-ahead position.
^
Observe safety precautions for working on airbags,
^
If these procedures are not observed, the airbag system may not function properly during vehicle operation!
^
Remove airbag control module.
^
Disengage clip for airbag.
^
Disconnect connector for steering angle sensor (arrow).
^
Remove steering wheel.
^
Remove airbag control module.
Removing steering column switch
^
Disengage steering column adjustment.
^
Remove steering column completely.
^
Remove bolt-1- (2x). Tightening torque 3 Nm.
^
Remove handle -2-.
^
Remove two Phillips head screws (arrows).
