1 Series E81 116i (N43) 3-door
Pretension drive belt tensioning device at screw (1) as far as it
will go in direction of arrow and lock with special tool 11 3 340 .
Remove drive belt.
Important!
Tensioning device for drive belt is under high spring pressure.
Press in special tool 11 3 340 on tensioning device (1) as far
as it will go (see arrow).
Make sure drive belt is in correct installation position.
Assemble engine.
RA Replacing alternator drive belt (N43)
