1 Series E81 116i (N43) 3-door
Secure special tool 11 8 692 to cylinder head with special tool
11 8 693 .
Note:
The timing is correctly adjusted when the special tool 11 8 691
rests without any gap on the cylinder head or is raised up to
0.5 mm to inlet side.
Note:
The timing is correctly adjusted when the special tool 11 8 691
rests without any gap on the cylinder head or is raised up to
1.0 mm to inlet side.
If necessary, adjust camshaft timing.
RA Checking camshaft timing (N43)
