1 Series E81 116i (N43) 3-door
41 11 043
Replacing front section of left engine support
Read contents of Body, General.
Refer to the description texts of the KSD CD (FRU 41 11 043)
for details of stripping-down and rigging work.
Remove or cover those vehicle components in the repair area
which are susceptible to heat or dust.
Use only approved spot-welding apparatus for repairs.
Place vehicle on straightening bench.
Following new body parts are required (refer to EPC):
-
(1) Engine carrier, front
Mark severance cut (1) in accordance with measurement a and
cut engine carrier.
Important!
Cut outer metal sheet only.
Measurement a=130 mm from front edge of sleeve
Installation:
Weld in reinforcing panels at all severance cuts.
Open weld joints in areas (1).
RA Replacing front section of left engine support
