1 Series E81 118d (N47) 3-door
61 33 040
Removing and installing/replacing a fanfare
horn
Necessary preliminary tasks:
•
Remove front wheel arch cover
Disconnect plug connection (4).
Release nut (1) and remove fanfare horn (3) from bracket (2).
Tightening torque 61 33 1AZ
.
RA Removing and installing/replacing a fanfare horn
BMW AG - TIS
17.01.2013 17:46
Issue status (12/2007) Valid only until next DVD is issued
