1 Series E81 118i (N46T) 3-door
51 16 ...
Removing and installing/replacing mounting
for cup holder at front
Necessary preliminary tasks:
•
Remove storage compartment
Release screws (1).
Remove holder (2) and trim (3).
Installation:
Spring (4) on holder (2) must not be damaged or missing.
Installation:
Following parts must not be damaged or missing:
1
Screw mountings
2
Spring
3
Trim
RA Removing and installing/replacing mounting for cup holder at front
BMW AG - TIS
18.01.2013 23:56
Issue status (12/2007) Valid only until next DVD is issued
