1 Series E81 118i (N46T) 3-door
51 16 ...
Removing and installing/replacing trim for
gearshift
Important!
Risk of damage!
When working on trim panel components, make sure that the
sensitive surfaces are not scratched or damaged.
Necessary preliminary tasks:
Version with controller:
•
Remove controller
Version with manual transmission:
•
Remove gaiter for gear lever
Version with automatic transmission:
•
Remove finisher for preselector lever
Pull trim (1) upwards and thereby release from retainers (2) and
catches (3).
Installation:
Cables must not be jammed.
Retainers (2) and catches (3) must not be damaged.
If replacing on version with controller:
Provide trim (1) with opening (2) for controller (3).
Note:
Opening (2) is marked on the underside of the trim (1).
RA Removing and installing/replacing trim for gearshift
