1 Series E81 118i (N46T) 3-door
11 36 Variable Camshaft Control
Type
Thread
Tightening specification
Measure
1AZ VANOS with sensor wheel to inlet
and exhaust camshafts
N46T
M10x86
Replace screw
Jointing torque
20 Nm
Torque angle
180
°
2AZ Solenoid valve and holder to cylinder
head
N46T
M6x12
9 Nm
AZD Variable Camshaft Control
