1 Series E81 130i (N52K) 3-door
Note:
On the M3 a ball joint is fitted in the guide arm.
Slacken nut (1).
Unscrew bolt towards rear and remove guide arm (2).
Installation:
Bolt head must point to rear.
Replace self-locking nut.
Tightening torque 33 32 3AZ
.
After installation:
•
Perform chassis alignment check
RA Replacing a guide arm
