1 Series E81 130i (N52K) 3-door
Crimp butt connector on preassembled wire end.
Refer to repair instructions:
Crimping on stop parts
Push shrink-fit hose (8) onto free wire end.
Crimp unused wire end to butt connector.
Pull shrink-on sleeve over butt connector.
RA Butt connector for repairing a plug connection
