1 Series E81 130i (N52K) 3-door
Installation of the passenger power window switch is described
separately from removal.
Attach switch block adapter (1) to passenger power window
switch (2).
Feed cable tie (3) in direction of arrow through bores in front
passenger power window switch (2), then through bore in door
trim panel (5).
Insert cable tie (4) from rear through lower bore in door trim
panel (5). Feed cable tie (4) in direction of arrow through front
passenger power window switch (2) and from front through upper
bore in door trim panel (5).
Insert front passenger power window switch (2) in door trim
panel.
Installation:
Make sure front passenger power window switch (2) is correctly
seated in door trim panel (5).
Feed switch block adapter lead (3) through opening (4).
Feed in cable ties (1 and 2), tighten and cut off.
