1 Series E81 130i (N52K) 3-door
11 14 Transmission closing plate
Type
Thread
Tightening specification
Measure
1AZ ASA screws
(4 x)
Transmission cover plate to
crankcase.
The end faces of the aluminium
screw heads are painted blue.
N52K
M6 x 16
Replace screws.
Thread repairs exclusively
with aluminium Helicoil
threaded insert.
Jointing torque and angle
of rotation must be
observed without fail.
Jointing torque
4 Nm
Torque angle
45
°
AZD Transmission closing plate
