1 Series E81 130i (N52K) 3-door
11 72 Air pump, lines and control valves
Type
Thread
Tightening specification
Measure
1AZ Secondary air valve to cylinder head
N52K
M6
8 Nm
2AZ Secondary air pump to mounting
bracket/pump carrier
N52K
M6
8 Nm
3AZ Intake hose / intake line to body
N52K
M6
8 Nm
AZD Air pump, lines and control valves
