1 Series 120d (N47) Coupe
11 42 020
Removing and installing/replacing complete
main flow oil filter (N47, N47S)
Necessary preliminary tasks:
•
Drain coolant
•
Remove guide tube for oil dipstick
•
Remove throttle valve
•
Change engine oil
To avoid excess discharge of oil when removing the full flow oil
filter:
Place rag under oil filter housing.
Disconnect plug connection on oil pressure switch.
Release screws (2).
Release screws (1).
Lift out oil filter housing.
RA Removing and installing/replacing complete main flow oil filter (N47, N47S)
