1 Series E87 118i (N43) 5-door
63 12 870
Replacing ignition unit for left xenon
headlight (with xenon bulb) (up to 03/2007)
Warning!
Version with xenon headlights: Danger to life due to high
voltage! Therefore, before removing, disconnect all
components from the power supply (lighting system and
ignition off).
Work on the entire xenon lighting system (control unit, ignition
unit with bulb) may only be carried out by specialist personnel.
Follow instructions for handling light bulbs (exterior lights).
Important!
Ignition unit and xenon bulb are viewed as a single
component and must not be separated.
N52:
Necessary preliminary tasks:
•
Remove intake filter housing
Unlock spring wire clips (1) in direction of arrow.
Remove cover (2) in upward direction from headlight (3).
Installation:
Make sure cover (2) is correctly seated on headlight (3).
