1 Series E87 120d (N47) 5-door
Note:
Pressure line of clutch slave cylinder remains connected.
Important!
Slowly relieve tension on clutch slave cylinder otherwise air is
drawn in through sealing sleeve.
Release nuts and remove clutch slave cylinder.
Tasks are described in Removing clutch slave cylinder.
Unfasten plug (1) of zero gear sensor (on transmission).
Release screws.
Tightening torque 23 00 1AZ
.
Important!
Do not allow the transmission to hang off from the
transmission input shaft as this will deform the clutch plate.
Pull out transmission towards rear and remove.
Installation:
Check that dowel sleeves are correctly seated.
Replace damaged dowel sleeves.
Ensure correct position of cover plate.
RA Removing and installing transmission (GS6-37DZ) N47, N47S
