1 Series 120i (N43) Convertible
Place dial gauge sensor on rim shoulder.
Turn wheel by hand and measure max. radial runout.
Carry out measurement on both rim shoulder sides.
Note:
Dial gauge must be vertical to rim shoulder.
Position sensor on rim flange.
Turn wheel by hand and measure max. lateral runout.
Carry out measurement on both rim flanges.
Note:
Dial gauge must be vertical to rim flange.
Important!
Avoid transformation errors during subsequent installation
tasks.
RA Checking rim for face and radial runout
