1 Series 120i (N43) Convertible
52 16 405
Replacing backrest cover on front left or right
seat (sports/electric)
Special tools required:
•
52 0 050
Necessary preliminary tasks:
•
Remove front seat
•
Remove guide sleeves
•
Remove cover for release mechanism
Version with seat heating only:
Unfasten plug connection (1) and disconnect.
Detach cable strap (2).
Release wiring harness from cable holders on seat mechanism.
Important!
Feed the wiring harness carefully through the seat and
backrest mechanism as the edges of the frame can be sharp.
Detach backrest cover (1) from backrest frame.
RA Replacing backrest cover on front left or right seat (sports/electric)
BMW AG - TIS
15.01.2013 20:41
Issue status (12/2007) Valid only until next DVD is issued
