1 Series 120i (N43) Convertible
11 31 Camshaft
Type
Thread
Tightening specification
Measure
1AZ Camshaft bearing cap to bearing
bridge, cylinder head
N43
M6
Tapered flat nut
10 Nm
2AZ Support block, high-pressure pump,
to cylinder head
N43
M6
Tapered flat nut
10 Nm
3AZ Bearing bridge, vacuum pump
N43
M6
Tapered flat nut
10 Nm
4AZ Chain drive module to cylinder head
N43
M6x35
8 Nm
5AZ Guide rail to crankcase
N43
M8
20 Nm
6AZ Guide rail to cylinder head
N43
M7
Guide pin
14 Nm
7AZ Chain tensioner to cylinder head
N43
M22 x 1.5
Replace sealing ring
65 Nm
8AZ Screw plug in cylinder head
N43
M18x1.5
Replace sealing ring
25 Nm
AZD Camshaft
