3 Series E30 324td (M21) TOUR
11 12 Cylinder Head and Cover
Type
thread
tightening specification
Measure
3AZ Cylinder head bolts
Replace, wash and oil cylinder head
bolts.
M21
torque
50 Nm
Torsion angle (screws no.
1 - 10)
90
°
Torsion angle (screws no.
11 - 14)
73
°
warm-running time
15 min
torque angle
90
°
4AZ Cylinder head bolts
Replace, wash and oil cylinder head
bolts.
M30
torque
60 Nm
settling time
20 min
torque
80 Nm
warm-running time
25 min
torque angle
35
°
AZD Cylinder Head and Cover
