3 Series E36 316g (M43) COMP
54 11 Folding sunroof
Type
thread
tightening specification
Measure
1AZ Frame on body
E36 / compact
6.5 Nm
2AZ Winder on front hood
Install bolts with bolt cement.
E36 / compact
3.5 Nm
3AZ Engine on frame
E36 / compact
3.5 Nm
4AZ Top profile strip for net wind deflector
on release lever
E36 / compact
0.6 Nm
5AZ Release lever for net wind deflector
on frame
E36 / compact
1.3 Nm
6AZ Bottom profile strip for net wind
deflector on frame
E36 / compact
1.1 Nm
AZD Folding sunroof
