3 Series E36 316i (M43) COMP
Schematics:
1.
Switch on luggage compartment lid lock
2.
Basic Module IV
3.
Relay for luggage compartment lid locking device
4.
Drive for central locking on luggage compartment lid
Top view of connecting strip
Vehicles with air-conditioning system
15
Relay for door-lock heating
16
Thermostatic switch device or relay for daytime-driving light
17
Relay for front fog lights
Vehicles with heating
15
Relay for door-lock heating
16
Thermostatic switch device or relay for daytime-driving light
17
Relay for front fog lights
ABS control unit
RA Replacing control modules behind glove compartment
