3 Series E36 316i (M43) SAL
13 00 Checking/adjusting engine and exhaust E36 / M43 B 18
Engine designation
18 4 E2
Inspection prerequisite: engine at operating temperature
Idle speed
without consumers
1rpm
±
50
900
with air conditioner
1rpm
±
50
900
with drive range selected
1rpm
±
50
760
max. engine speed
1rpm
±
50
6200
CO vol. before catalytic converter
%
0.7
±
0.5
CO vol. with catalytic converter
%
≤
0.5
TD Checking/adjusting engine and exhaust, E36, M43, B 18
BMW AG - TIS
16.02.2013 09:09
Issue status (12/2007) Valid only until next DVD is issued
