3 Series E36 318i (M43) CONVER
32 00 Front Axle Wheel Alignment E36 CONVERTIBLE COUPE SAL TOUR Low-slung sports suspension
Observe test conditions
(see 32-00)
Total toe
0
°
18'
±
8'
Camber a)
- 58'
±
30'
Camber a) from mod 95
- 51'
±
30'
Toe difference angle with 20
°
inside wheel lock a)
- 1
°
34'
±
30'
Caster a)
With
±
10
°
wheel lock
3
°
50'
±
30'
With
±
20
°
wheel lock
3
°
57'
±
30'
Front wheel displacement
0
°
±
15'
Maximum wheel lock
Inside wheel
approx.
°
44
Outside wheel
approx.
°
36
Turning circle
approx. m
10.4
a) Difference between left/right max. 30'
