3 Series E36 318is (M42) SAL
Installation:
Retainer must fit central to the counterpiece.
Press on plate and install plugs.
Loosen cable straps.
Disconnect plugs (1 and 2).
Unlock and pull off plug receptacle in forwards direction.
Remove screws and fold up cushion shell together with wire
harness.
Remove screws (1 and 2) and remove backrest control drive.
RA Removing and installing or replacing seat backrest frame on left or right front
BMW AG - TIS
02.02.2013 19:54
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 2 -
