3 Series E36 320i (M52) COUPE
Version 1
Take off cap on connections.
Disconnect plug connection (1).
Release nut (2) and disconnect battery positive lead.
Tightening torque, 12 31 1AZ
.
Version 2
Unlock and detach plug connection (1).
Release nut (2) and disconnect battery positive lead.
Tightening torque, 12 31 1AZ
.
Version without idler pulley:
Release alternator screws in succession while simultaneously
gripping alternator firmly.
Remove alternator.
Version with idler pulley:
Remove cover from idler pulley (1).
Release screw and remove idler pulley (1).
Release screw and remove alternator (2).
RA Removing and installing or replacing alternator (M52, M52TU, S50US, S52, M54, M5
