3 Series E36 320i (M52) COUPE
32 00 620
Adjusting rear axle (Saloon/Sedan, Coupé,
Convertible, Touring)
Special tools required:
•
32 3 030
•
32 3 080
E36 only:
Important!
Eccentric bolts must be replaced prior to camber adjustment!
Note:
A camber change always means a toe change as well. The
camber must therefore be adjusted first.
Adjusting camber:
Replace eccentric bolt, compress/deflect car and perform
chassis/wheel alignment check again.
Replace nut (2) and tighten down to 5 Nm.
Turn eccentric bolt (1) to adjust camber to setpoint value.
Tighten nut (2).
Tightening torque 33 32 11AZ
.
RA Adjusting rear axle (Saloon/Sedan, Coupé, Convertible, Touring)
