3 Series E36 320i (M52) COUPE
63 99 201
Replacing halogen bulb for left or right front
fog lamp
Warning!
Follow instructions for handling light bulbs (exterior lights).
Unclip headlight by inserting a screwdriver through upper
aperture.
Pull off connector. Disconnect steel-wire clamp and pull out light
bulb.
Roadster:
Unclip plate.
Unfasten screws, pry out headlight insert and remove connector.
Disconnect wire spring clip and remove light bulb.
Installation:
•
Make sure spring wire clip is correctly engaged
•
Note bulb type.
RA Replacing halogen bulb for left or right front fog lamp
