3 Series E36 323i (M52) COUPE
41 00 ...
Gap dimensions for doors/engine hood and trunk lid E36 4-door
Door seams and lid seams 4.3 - 5.3 mm
Max. permissible parallel deviation: 0.5 mm
Plane displacement A for adjacent body parts at rear = max. 1 mm towards inside.
RA Gap dimensions for doors/engine hood and trunk lid E36 4-door
