3 Series E36 323ti (M52) COMP
Caution!
If adjustment travel is less than 8.5 mm, the VANOS
adjustment unit must be removed and reset,
refer to 11 36 010
Remove compressed air connection.
Remove special tools 11 3 450 and 12 6 410.
Fit oil pressure line with new seals.
Tightening torque,
refer to Technical Data 11 36 2AZ
Install solenoid-valve plug-in connection.
Relieve tension on special tool 11 4 220 and remove.
RA Adjusting camshaft timing (M52/S52)
