3 Series E36 323ti (M52) COMP
54 11 215
Replacing profile strips for net wind deflector
Remove and install net insert for wind deflector,
refer to 54 11 205.
Release screws (1) and remove lower profile strip (2) towards
rear/top from frame of folding sunroof (3).
Installation:
Tightening Torque,
refer to Technical Data 54 11 6AZ.
Release screws (1) and remove upper profile strip (2) towards top
from release levers (3).
Installation:
Tightening Torque,
refer to Technical Data 54 11 4AZ.
RA Replacing profile strips for net wind deflector
