3 Series E36 323ti (M52) COMP
63 10
Headlight adjustment, RHD/LHD vehicles
E 36 compact
When crossing the border into countries where vehicles
drive on the opposite side of the road to the country in
which a vehicle is licensed, the asymmetric wedge on the
low-beam headlight must be covered. Use a commercially
available waterproof black adhesive tape. Remove any
possible remaining traces of adhesive with adhesive
remove or suitable cleaning agents (thinning or alcohol).
The following pictures show the covered areas in question.
Left headlight in direction of travel:
Marking angles are provided on the cover glass.
RA Headlight adjustment, RHD/LHD vehicles
