3 Series E36 M3 (S50) COUPE
Continue rotating crankshaft in direction of rotation until two more
screws are accessible on the intake end of the VANOS unit.
Insert these two screws and tighten down to 10 Nm.
Tighten down two accessible screws on exhaust end of VANOS
gear to 10 Nm.
Continue to rotate crankshaft in direction of rotation until
remaining two screws on intake end of VANOS unit are
accessible.
Insert these two screws and tighten down to 10 Nm.
Tighten down last two screws on exhaust end of VANOS gear to
10 Nm.
RA Replacing all camshafts (S50 B32)
