3 Series E36 M3 (S52) CONVER
54 34 200
Removing and installing/replacing motor for
convertible top lock (power/fully-automatic)
Removing and installing finisher on convertible top lock,
refer to 54 34 125
Pull off plug connections (1) and (2), unlock both housings and
remove from bracket. Loosen nut (3), pull motor (4) downwards to
remove and slide off input shaft (5).
Installation:
The two input shafts (5) must be at "Open" limit position
(microswitch (S8) tripped).
