3 Series E36 M3 (S52) CONVER
61 61 250
Replacing windshield wiper motor
Note:
Prior to removal, allow wiper motor to run into rest position (if still
possible).
Necessary preliminary tasks:
•
Disconnect battery negative lead.
•
Remove complete bracket for windshield wiper system.
Note:
Drive rods remain fitted, illustrated without drive rods for sake of
clarity.
Unfasten nut on motor crank and pry off crank from motor.
Unfasten screws and remove wiper motor from console.
Tightening torque, 61 61 1AZ
.
Installation:
Replace screws.
Screw new wiper motor onto wiper bracket, connect to vehicle
wiring harness and run into rest position.
RA Replacing windshield wiper motor
BMW AG - TIS
10.02.2013 10:56
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
