3 Series E36 M3 (S52) CONVER
Wrap driver's side wiper shaft in insulating tape to prevent
scratching cowl panel during removal.
Release nuts (2) on left and right.
Installation:
Tightening torque, 61 61 5AZ .
Remove mounting bracket for windshield wiper system complete
with motor from body as shown in following illustrations.
Installation:
Tie back wiring on holder with a cable strap.
RA Removing and installing complete mounting bracket for windshield wiper system wi
