3 Series E36 M3 (S52) CONVER
Push forward levers on connectors and take out connectors.
Installation:
When inserting a connector, lever must be in forward position.
Unscrew button for light switch and pull out instrument carrier
sideways.
Installation:
When replacing instrument carrier, convert, adjust, and code
coding plug.
Refer to 62 10 000.
Tests 15 and 09
RA Removing and installing complete instrument carrier
BMW AG - TIS
10.02.2013 11:18
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 2 -
