3 Series E36 M3 (S52) CONVER
34 11 Front Wheel Brakes E36
Different thicknesses on brake linings
max. mm
0.01
Radial runout of brake lining (measured at largest
∅
of
brake lining)
Disc installed
max. mm
Disc removed
max. mm
Surface roughness of braking surfaces (precision-turned)
Ra
µ
0.5 ... 3.5
Brake disc diameter
mm
286
M 3:
315
