3 Series E36 M coupe (S50) COUPE
Install seal from bottom left to bottom right and press on.
Caution!
The basic filler must have hardened!
Treat windshield and body around glued area with BMW-approved
materials (repair kit, Sourcing Reference: BMW Parts Service),
refer to 51 31 ...
Note:
Note ventilation time!
Stick on 1 spacer buffer (2) in each case in center and at
distances (A) and (B) from center of cowl panel.
Dimensions:
(A) 500 mm
(B) 500 mm
(C) 18 mm
1.
Windshield
2.
Spacer buffer
3.
Glue bead
4.
Windshield
Cut nozzle to size.
Dimensions:
(A) 8
-2
mm
(B) 11
-2
mm
Note:
For an even application of adhesive bead:
Use a cartridge gun (operated pneumatically or electrically,
sourcing reference: BMW Parts Service).
Check expiry date of glue!
RA Removing and installing windshield (Z3 Roadster, M Roadster, Z3 Coupé, M Coupé)
