3 Series E36 M coupe (S50) COUPE
51 36 047
Replacing trim on rear left or right door
window (Z3 Coupé, M Coupé)
Note:
Ensure car is at room temperature (> 18
°
C),
if necessary, heat up adhesive area.
Adhesion is not guaranteed below this temperature
(formation of condensation water).
Remove trim (1) from side window (2) with special
tool 00 9 318 (universal wedge) or special tool 00 9 322
(adhesive wedge).
Installation:
Treatment of adhesive area on side window:
-
Clean with spirit
-
Air drying time at least 2 minutes
-
Apply a thin coat of glass primer 205/5 or Sika bonding
agent 205/5 (sourcing reference: BMW Parts Service)
-
Air drying time at least 2 minutes
Installation:
-
Detach liner (3) (protective film on adhesive tape)
-
Align trim (2) on door window and, applying firm thumb
pressure, press trim down over entire adhesive area
-
Wipe off remnants of glass primer or bonding agent with
a dry cloth otherwise spots will appear on the door
window
1.
Adhesive tape
2.
Plate
