3 Series E36 M coupe (S52) COUPE
11 12 Cylinder head with cover S52 B 32
Cylinder head height, original dimension (cylinder head
must not be machined)
mm
140
Valve guides are not available as replacement parts.
Valve guide inner dia. (installed)
Standard
mm
6.0 H7
Size 1
mm
6.1 H7
Size 2
mm
6.2 H7
Tilt clearance (between valve and valve guide)
max. mm
0.5
Camshaft bearing
Pilot bearing (1) width
mm
20 d8
TD Cylinder head with cover, S52, B 32
BMW AG - TIS
10.02.2013 04:14
Issue status (12/2007) Valid only until next DVD is issued
