3 Series E36 M coupe (S52) COUPE
11 25 Pistons with Rings and Pins S52 B 32
Pistons and pins are matched - only replace them
together.
Measuring point "A" (position)
mm
9.5
Piston diameter (measuring point"A")
Standard
mm
86.365
±
0.009
1st oversize
mm
86.565
±
0.009
Piston running clearance
0.026 ... 0.058
Max. total wear clearance between piston and cylinder
(engine operated)
mm
0.113
TD Pistons with Rings and Pins, S52, B 32
